- 32 carriers
- Bobbin Ø 87 mm x 320 mm = 1,732 ccm
- Speed 200 horn gear rpm
- Exchangeable horn gear inserts
- Take-off speed adjustable by change gear
- Optionally available: PLC control
for setting the take-off speed - Cylindrical take-off discs
from Ø 500 mm – Ø 1,000 mm - Optionally available:
Electromechanical guard for core material - Optionally available: Braid take-up
on drum laterally at the underframe - Optionally available:
Electrical connection of a HERZOG
take-up / pay-off - Optionally available: Electronic
height adjustment of braiding die - Carrier protection with lifting door
and electronic monitoring - Optionally available: Cabin
- Optionally available: Heat setting
unit mounted on braiding machine
Recommended for the production of ropes up to 32 mm diameter.
